Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2025-02-14 14:27:12 (GMT)
 Μέγεθος
 M 1.7
 Γεωγρ. Πλάτος
 39.2200° Β
 Γεωγρ. Μήκος
 21.6293° Α
 Εστιακό Βάθος
 10 χμ
 Αρ. αφίξεων
 24
 Επίκεντρο 29.9 χμ ΔΝΔ της Καρδίτσας
39.1 χμ ΝΝΔ των Τρικάλων
228.8 χμ ΒΔ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
GR201Y10.2 81 P14:27:15.14 0.11.0M
GR201Y10.2 81 S14:27:17.34 0.31.0M
TETRHL33.5294 P14:27:18.22 -0.41.0M
TETRHL33.5294 S14:27:22.98 -0.51.0M
THLHL50.6 41 P14:27:21.46 0.11.0M
THLHL50.6 41 S14:27:28.08 -0.11.0M
GR171Y57.1 0 P14:27:22.71 0.31.0M
GR171Y57.1 0 S14:27:30.04 -0.11.0M
PVOHP67.7188 P14:27:24.07 0.01.0M
PVOHP67.7188 S14:27:32.75 -0.31.0M
ANXHP74.1160 P14:27:25.03 -0.21.0M
ANXHP74.1160 S14:27:34.60 -0.41.0M
GR241Y76.7140 P14:27:25.24 -0.41.0M
GR241Y76.7140 S14:27:35.40 -0.31.0M
GR211Y77.9 77 P14:27:26.01 0.31.0M
GR211Y77.9 77 S14:27:36.05 0.11.0M
PDOHP79.1209 P14:27:26.53 0.61.0M
PDOHP79.1209 S14:27:36.21 0.01.0M
AGRPCL92.0175 P14:27:27.43 -0.51.0M
AGRPCL92.0175 S14:27:39.91 0.11.0M
LKD2HT96.7240 P14:27:29.09 0.31.0M
LKD2HT96.7240 S14:27:41.51 0.21.0M
FSKHP125.3228 P14:27:33.52 0.41.0M
FSKHP125.3228 S14:27:49.92 0.91.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2025ddmt
    Description
      region name: Greece
Origin:
    Date                   2025-02-14
    Time                  14:27:12.28
    Latitude              39.2200 deg  +/-      0 km
    Longitude             21.6293 deg  +/-      0 km
    Depth                      10 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.31 s
    Azimuthal gap              66 deg

2 Network magnitudes:
    MLv       1.72 +/- 0.17  10
    M         1.72           10 preferred

24 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    GR20  1Y    0.1  81  P       14:27:15.14   0.1 M  1.0  GR20
    GR20  1Y    0.1  81  S       14:27:17.34   0.3 M  1.0  GR20
    TETR  HL    0.3 294  P       14:27:18.22  -0.4 M  1.0  TETR
    TETR  HL    0.3 294  S       14:27:22.98  -0.5 M  1.0  TETR
    THL   HL    0.5  41  P       14:27:21.46   0.1 M  1.0  THL
    THL   HL    0.5  41  S       14:27:28.08  -0.1 M  1.0  THL
    GR17  1Y    0.5   0  P       14:27:22.71   0.3 M  1.0  GR17
    GR17  1Y    0.5   0  S       14:27:30.04  -0.1 M  1.0  GR17
    PVO   HP    0.6 188  P       14:27:24.07  -0.0 M  1.0  PVO
    PVO   HP    0.6 188  S       14:27:32.75  -0.3 M  1.0  PVO
    ANX   HP    0.7 160  P       14:27:25.03  -0.2 M  1.0  ANX
    ANX   HP    0.7 160  S       14:27:34.60  -0.4 M  1.0  ANX
    GR24  1Y    0.7 140  P       14:27:25.24  -0.4 M  1.0  GR24
    GR24  1Y    0.7 140  S       14:27:35.40  -0.3 M  1.0  GR24
    GR21  1Y    0.7  77  P       14:27:26.01   0.3 M  1.0  GR21
    GR21  1Y    0.7  77  S       14:27:36.05   0.1 M  1.0  GR21
    PDO   HP    0.7 209  P       14:27:26.53   0.6 M  1.0  PDO
    PDO   HP    0.7 209  S       14:27:36.21  -0.0 M  1.0  PDO
    AGRP  CL    0.8 175  P       14:27:27.43  -0.5 M  1.0  AGRP
    AGRP  CL    0.8 175  S       14:27:39.91   0.1 M  1.0  AGRP
    LKD2  HT    0.9 240  P       14:27:29.09   0.3 M  1.0  LKD2
    LKD2  HT    0.9 240  S       14:27:41.51   0.2 M  1.0  LKD2
    FSK   HP    1.1 228  P       14:27:33.52   0.4 M  1.0  FSK
    FSK   HP    1.1 228  S       14:27:49.92   0.9 M  1.0  FSK

12 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    GR20  1Y    0.1  81  MLv     1.53 -0.19    1.49564
    TETR  HL    0.3 294  MLv     1.41 -0.30   0.299838
    THL   HL    0.5  41  MLv     1.59 -0.13   0.101941
    GR17  1Y    0.5   0  MLv     1.71 -0.00   0.153705
    PVO   HP    0.6 188  MLv     1.99  0.28   0.226666
    ANX   HP    0.7 160  MLv     1.70 -0.02   0.107542
    GR24  1Y    0.7 140  MLv     1.55 -0.17   0.0734925
    GR21  1Y    0.7  77  MLv     1.56 -0.16   0.0740679
    PDO   HP    0.7 209  MLv     1.87  0.15   0.148081
    AGRP  CL    0.8 175  MLv     1.71 -0.01   0.0894337
    LKD2  HT    0.9 240  MLv     2.03  0.31   0.178178
    FSK   HP    1.1 228  MLv     2.39  0.67    0.28858
