Earthquake Information
 Origin Time
2024-10-16 02:34:00 (GMT)
 Magnitude
M 2.1
 Latitude
38.6776° N
 Longitude
20.6322° E
 Focal Depth
2 km
 # of Arrivals
32
 Location 4.3 km S of Leukada
32.0 km SSW of Preveza
281.3 km WNW of Athens
 Solution type
automatic
 Files / Links
QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
EVGIHT6.6162 P02:34:01.52 0.21.0A
NYDRHT7.0 55 P02:34:00.88 -0.51.0A
LKD2HT12.6 10 P02:34:01.03 -1.31.0A
TSLKHT16.5 7 P02:34:01.71 -1.31.0A
FSKHP25.0194 P02:34:04.09 -0.41.0A
PDOHP48.7100 P02:34:08.04 -0.41.0A
DMLNHT53.8205 P02:34:08.94 -0.41.0A
VLSHL55.8184 P02:34:09.09 -0.51.0A
LX10HA58.9199 P02:34:09.66 -0.51.0A
RTZLHT68.0170 P02:34:11.11 -0.61.0A
PLEVHP73.6113 P02:34:12.39 -0.31.0A
PVOHP77.9 95 P02:34:13.29 -0.11.0A
ORTHHL92.1176 P02:34:17.19 1.51.0A
TETRHL92.6 37 P02:34:14.81 -1.01.0A
GR19B1Y96.8327 P02:34:16.91 0.41.0A
RLSHL100.2133 P02:34:16.93 -0.21.0A
PRMDHP102.9 23 P02:34:17.84 0.31.0A
VVKHP106.4105 P02:34:17.63 -0.61.0A
ANXHP112.3 94 P02:34:18.42 -0.81.0A
EFPHP114.2104 P02:34:18.80 -0.71.0A
GR201Y114.6 57 P02:34:18.19 -1.31.0A
DROHP124.0130 P02:34:20.47 -0.41.0A
LAKAHA126.9112 P02:34:23.32 2.01.0A
TRIZCL130.0105 P02:34:21.01 -0.81.0A
KEKHL135.8328 P02:34:22.69 0.11.0A
PSAMCL140.7106 P02:34:22.88 -0.51.0A
AGGHT152.4 75 P02:34:24.98 0.01.0A
GURHP170.5118 P02:34:29.66 2.11.0A
PENTHL174.3 14 P02:34:30.43 2.41.0A
GR211Y179.9 64 P02:34:30.61 1.81.0A
GR181Y210.8 56 P02:34:34.86 1.81.0A


  Solution details

Event:
    Public ID              nkua2024uifm
    Description
      region name: Greece
Origin:
    Date                   2024-10-16
    Time                  02:33:59.81  +/-    0.2 s
    Latitude              38.6776 deg  +/-      2 km
    Longitude             20.6322 deg  +/-      2 km
    Depth                       2 km
    Agency                 HA
    Mode                   automatic
    Status                 NOT SET
    Residual RMS             1.04 s
    Azimuthal gap             122 deg

2 Network magnitudes:
    MLv       2.07 +/- 0.15  21
    M         2.07           21 preferred

32 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    EVGI  HT    0.1 162  P       02:34:01.52   0.2 A  1.0  EVGI
    NYDR  HT    0.1  55  P       02:34:00.88  -0.5 A  1.0  NYDR
    LKD2  HT    0.1  10  P       02:34:01.03  -1.3 A  1.0  LKD2
    TSLK  HT    0.1   7  P       02:34:01.71  -1.3 A  1.0  TSLK
    FSK   HP    0.2 194  P       02:34:04.09  -0.4 A  1.0  FSK
    PDO   HP    0.4 100  P       02:34:08.04  -0.4 A  1.0  PDO
    DMLN  HT    0.5 205  P       02:34:08.94  -0.4 A  1.0  DMLN
    VLS   HL    0.5 184  P       02:34:09.09  -0.5 A  1.0  VLS
    LX10  HA    0.5 199  P       02:34:09.66  -0.5 A  1.0  LX10
    RTZL  HT    0.6 170  P       02:34:11.11  -0.6 A  1.0  RTZL
    PLEV  HP    0.7 113  P       02:34:12.39  -0.3 A  1.0  PLEV
    PVO   HP    0.7  95  P       02:34:13.29  -0.1 A  1.0  PVO
    ORTH  HL    0.8 176  P       02:34:17.19   1.5 A  1.0  ORTH
    TETR  HL    0.8  37  P       02:34:14.81  -1.0 A  1.0  TETR
    GR19B 1Y    0.9 327  P       02:34:16.91   0.4 A  1.0  GR19B
    RLS   HL    0.9 133  P       02:34:16.93  -0.2 A  1.0  RLS
    PRMD  HP    0.9  23  P       02:34:17.84   0.3 A  1.0  PRMD
    VVK   HP    1.0 105  P       02:34:17.63  -0.6 A  1.0  VVK
    ANX   HP    1.0  94  P       02:34:18.42  -0.8 A  1.0  ANX
    EFP   HP    1.0 104  P       02:34:18.80  -0.7 A  1.0  EFP
    GR20  1Y    1.0  57  P       02:34:18.19  -1.3 A  1.0  GR20
    DRO   HP    1.1 130  P       02:34:20.47  -0.4 A  1.0  DRO
    LAKA  HA    1.1 112  P       02:34:23.32   2.0 A  1.0  LAKA
    TRIZ  CL    1.2 105  P       02:34:21.01  -0.8 A  1.0  TRIZ
    KEK   HL    1.2 328  P       02:34:22.69   0.1 A  1.0  KEK
    PSAM  CL    1.3 106  P       02:34:22.88  -0.5 A  1.0  PSAM
    AGG   HT    1.4  75  P       02:34:24.98  -0.0 A  1.0  AGG
    THL   HL    1.4  50  P       02:34:28.32   3.0 AX 0.0  THL
    GUR   HP    1.5 118  P       02:34:29.66   2.1 A  1.0  GUR
    PENT  HL    1.6  14  P       02:34:30.43   2.4 A  1.0  PENT
    GR21  1Y    1.6  64  P       02:34:30.61   1.8 A  1.0  GR21
    GR18  1Y    1.9  56  P       02:34:34.86   1.8 A  1.0  GR18

27 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    EVGI  HT    0.1 162  MLv     2.23  0.16    9.20951
    NYDR  HT    0.1  55  MLv     2.58  0.51    14.6245
    LKD2  HT    0.1  10  MLv     2.52  0.45    12.7454
    TSLK  HT    0.1   7  MLv     2.78  0.72    18.7296
    FSK   HP    0.2 194  MLv     1.51 -0.56   0.605309
    PDO   HP    0.4 100  MLv     2.07  0.00   0.570881
    DMLN  HT    0.5 205  MLv     1.96 -0.10   0.456544
    VLS   HL    0.5 184  MLv     2.00 -0.07   0.320643
    LX10  HA    0.5 199  MLv     2.20  0.14   0.428552
    RTZL  HT    0.6 170  MLv     2.17  0.10   0.339536
    PLEV  HP    0.7 113  MLv     2.07  0.01    0.25454
    PVO   HP    0.7  95  MLv     2.17  0.10   0.304877
    ORTH  HL    0.8 176  MLv     2.04 -0.03   0.189161
    TETR  HL    0.8  37  MLv     2.04 -0.02   0.190782
    GR19B 1Y    0.9 327  MLv     2.53  0.46   0.552913
    RLS   HL    0.9 133  MLv     1.86 -0.21   0.114782
    PRMD  HP    0.9  23  MLv     1.90 -0.17   0.120699
    VVK   HP    1.0 105  MLv     1.30 -0.77   0.137969
    ANX   HP    1.0  94  MLv     2.27  0.20   0.256761
    EFP   HP    1.0 104  MLv     2.19  0.12   0.209381
    GR20  1Y    1.0  57  MLv     1.75 -0.32   0.0752081
    DRO   HP    1.1 130  MLv     1.88 -0.18   0.192602
    LAKA  HA    1.1 112  MLv     1.99 -0.08   0.113963
    TRIZ  CL    1.2 105  MLv     2.03 -0.04   0.120259
    KEK   HL    1.2 328  MLv     1.73 -0.34   0.107684
    PSAM  CL    1.3 106  MLv     2.00 -0.07   0.0989277
    AGG   HT    1.4  75  MLv     2.12  0.05   0.0893373
