Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-12-27 10:02:36 (GMT)
Πανεπιστήμιο Αθηνών - Εργαστήριο Σεισμολογίας
+−
10 km
5 mi
Leaflet | Tiles © Esri
 Μέγεθος
 M 1.8
 Γεωγρ. Πλάτος
 36.5180° Β
 Γεωγρ. Μήκος
 25.4983° Α
 Εστιακό Βάθος
 7 χμ
 Αρ. αφίξεων
 20
 Επίκεντρο 12.7 χμ ΒΒΑ της Θήρας
66.2 χμ Ν της Νάξου
225.7 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
THR2HT9.7216 P10:02:38.40 -0.11.0M
THR2HT9.7216 S10:02:39.78 -0.51.0M
THR8HT12.5188 P10:02:39.03 0.11.0M
THR8HT12.5188 S10:02:40.08 -0.91.0M
SFR2HI14.2202 P10:02:39.51 0.31.0M
SFR2HI14.2202 S10:02:41.43 -0.11.0M
SANTHL16.8192 P10:02:39.74 0.11.0M
SANTHL16.8192 S10:02:41.99 -0.41.0M
THERAHL16.9187 P10:02:39.68 0.01.0M
THERAHL16.9187 S10:02:42.05 -0.31.0M
THR5HT17.5230 P10:02:40.22 0.51.0M
THR5HT17.5230 S10:02:42.66 0.11.0M
AKROHT19.9207 P10:02:40.31 0.11.0M
AKROHT19.9207 S10:02:42.96 -0.21.0M
THR6HT20.1207 P10:02:40.42 0.21.0M
THR6HT20.1207 S10:02:43.04 -0.21.0M
THR9HT21.9215 P10:02:41.02 0.61.0M
THR9HT21.9215 S10:02:43.68 -0.11.0M
APEHL61.7 2 P10:02:47.26 0.21.0M
APEHL61.7 2 S10:02:55.12 -0.21.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024zkim
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-12-27
    Time                  10:02:36.17
    Latitude              36.5180 deg  +/-      1 km
    Longitude             25.4983 deg  +/-      1 km
    Depth                       7 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.25 s
    Azimuthal gap             185 deg

2 Network magnitudes:
    MLv       1.81 +/- 0.20   8
    M         1.81            8 preferred

20 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    THR2  HT    0.1 216  P       10:02:38.40  -0.1 M  1.0  THR2
    THR2  HT    0.1 216  S       10:02:39.78  -0.5 M  1.0  THR2
    THR8  HT    0.1 188  P       10:02:39.03   0.1 M  1.0  THR8
    THR8  HT    0.1 188  S       10:02:40.08  -0.9 M  1.0  THR8
    SFR2  HI    0.1 202  P       10:02:39.51   0.3 M  1.0  SFR2
    SFR2  HI    0.1 202  S       10:02:41.43  -0.1 M  1.0  SFR2
    SANT  HL    0.2 192  P       10:02:39.74   0.1 M  1.0  SANT
    SANT  HL    0.2 192  S       10:02:41.99  -0.4 M  1.0  SANT
    THERA HL    0.2 187  P       10:02:39.68   0.0 M  1.0  THERA
    THERA HL    0.2 187  S       10:02:42.05  -0.3 M  1.0  THERA
    THR5  HT    0.2 230  P       10:02:40.22   0.5 M  1.0  THR5
    THR5  HT    0.2 230  S       10:02:42.66   0.1 M  1.0  THR5
    AKRO  HT    0.2 207  P       10:02:40.31   0.1 M  1.0  AKRO
    AKRO  HT    0.2 207  S       10:02:42.96  -0.2 M  1.0  AKRO
    THR6  HT    0.2 207  P       10:02:40.42   0.2 M  1.0  THR6
    THR6  HT    0.2 207  S       10:02:43.04  -0.2 M  1.0  THR6
    THR9  HT    0.2 215  P       10:02:41.02   0.6 M  1.0  THR9
    THR9  HT    0.2 215  S       10:02:43.68  -0.1 M  1.0  THR9
    APE   HL    0.6   2  P       10:02:47.26   0.2 M  1.0  APE
    APE   HL    0.6   2  S       10:02:55.12  -0.2 M  1.0  APE

10 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    THR2  HT    0.1 216  MLv     2.07  0.26    12.4069
    THR8  HT    0.1 188  MLv     1.82  0.01    5.83512
    SFR2  HI    0.1 202  MLv     1.92  0.11    2.94899
    SANT  HL    0.2 192  MLv     1.76 -0.05     1.3324
    THERA HL    0.2 187  MLv     1.42 -0.40   0.782534
    THR5  HT    0.2 230  MLv     1.27 -0.54    4.22228
    AKRO  HT    0.2 207  MLv     1.80 -0.01    1.58859
    THR6  HT    0.2 207  MLv     2.04  0.23    4.83614
    THR9  HT    0.2 215  MLv     1.63 -0.19    3.46871
    APE   HL    0.6   2  MLv     2.36  0.55   0.569041
