Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-12-19 09:45:09 (GMT)
 Μέγεθος
 M 1.4
 Γεωγρ. Πλάτος
 36.4143° Β
 Γεωγρ. Μήκος
 25.4273° Α
 Εστιακό Βάθος
 6 χμ
 Αρ. αφίξεων
 22
 Επίκεντρο 0.6 χμ ΔΝΔ της Θήρας
77.0 χμ Ν της Νάξου
230.1 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
SFR2HI1.9149 P09:45:10.40 0.01.0M
SFR2HI1.9149 S09:45:11.33 0.01.0M
THR3HT2.4256 P09:45:10.15 -0.21.0M
THR3HT2.4256 S09:45:11.37 0.11.0M
THR2HT3.7 11 P09:45:10.48 0.01.0M
THR2HT3.7 11 S09:45:11.62 0.11.0M
THR8HT4.7100 P09:45:10.64 0.01.0M
THR8HT4.7100 S09:45:11.94 0.21.0M
SANTHL5.7150 P09:45:10.78 0.01.0M
SANTHL5.7150 S09:45:11.97 -0.11.0M
CMBOHT6.6343 P09:45:11.04 0.21.0M
CMBOHT6.6343 S09:45:11.99 -0.21.0M
THERAHL6.8141 P09:45:10.93 0.01.0M
THERAHL6.8141 S09:45:12.09 -0.21.0M
AKROHT6.8204 P09:45:11.09 0.21.0M
AKROHT6.8204 S09:45:12.59 0.31.0M
THR6HT7.0202 P09:45:11.04 0.11.0M
THR6HT7.0202 S09:45:12.20 -0.11.0M
THR5HT7.1272 P09:45:10.85 -0.11.0M
THR5HT7.1272 S09:45:12.45 0.11.0M
THR9HT8.9225 P09:45:11.39 0.21.0M
THR9HT8.9225 S09:45:12.67 -0.11.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024yvrx
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-12-19
    Time                  09:45:09.15
    Latitude              36.4143 deg  +/-      0 km
    Longitude             25.4273 deg  +/-      0 km
    Depth                       6 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.14 s
    Azimuthal gap              89 deg

2 Network magnitudes:
    MLv       1.43 +/- 0.23   9
    M         1.43            9 preferred

22 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    SFR2  HI    0.0 149  P       09:45:10.40   0.0 M  1.0  SFR2
    SFR2  HI    0.0 149  S       09:45:11.33   0.0 M  1.0  SFR2
    THR3  HT    0.0 256  P       09:45:10.15  -0.2 M  1.0  THR3
    THR3  HT    0.0 256  S       09:45:11.37   0.1 M  1.0  THR3
    THR2  HT    0.0  11  P       09:45:10.48  -0.0 M  1.0  THR2
    THR2  HT    0.0  11  S       09:45:11.62   0.1 M  1.0  THR2
    THR8  HT    0.0 100  P       09:45:10.64   0.0 M  1.0  THR8
    THR8  HT    0.0 100  S       09:45:11.94   0.2 M  1.0  THR8
    SANT  HL    0.1 150  P       09:45:10.78  -0.0 M  1.0  SANT
    SANT  HL    0.1 150  S       09:45:11.97  -0.1 M  1.0  SANT
    CMBO  HT    0.1 343  P       09:45:11.04   0.2 M  1.0  CMBO
    CMBO  HT    0.1 343  S       09:45:11.99  -0.2 M  1.0  CMBO
    AKRO  HT    0.1 204  P       09:45:11.09   0.2 M  1.0  AKRO
    AKRO  HT    0.1 204  S       09:45:12.59   0.3 M  1.0  AKRO
    THERA HL    0.1 141  P       09:45:10.93   0.0 M  1.0  THERA
    THERA HL    0.1 141  S       09:45:12.09  -0.2 M  1.0  THERA
    THR6  HT    0.1 202  P       09:45:11.04   0.1 M  1.0  THR6
    THR6  HT    0.1 202  S       09:45:12.20  -0.1 M  1.0  THR6
    THR5  HT    0.1 272  P       09:45:10.85  -0.1 M  1.0  THR5
    THR5  HT    0.1 272  S       09:45:12.45   0.1 M  1.0  THR5
    THR9  HT    0.1 225  P       09:45:11.39   0.2 M  1.0  THR9
    THR9  HT    0.1 225  S       09:45:12.67  -0.1 M  1.0  THR9

11 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    SFR2  HI    0.0 149  MLv     1.60  0.17    2.84685
    THR3  HT    0.0 256  MLv     1.96  0.52    16.4242
    THR2  HT    0.0  11  MLv     2.06  0.62    16.7539
    THR8  HT    0.0 100  MLv     1.36 -0.07    3.16359
    SANT  HL    0.1 150  MLv     1.44  0.01    1.20517
    CMBO  HT    0.1 343  MLv    -0.04 -1.47   0.0494811
    AKRO  HT    0.1 204  MLv     1.24 -0.19   0.933388
    THERA HL    0.1 141  MLv     1.00 -0.43   0.537335
    THR6  HT    0.1 202  MLv     1.53  0.10     3.1809
    THR5  HT    0.1 272  MLv     1.51  0.08    13.3836
    THR9  HT    0.1 225  MLv     1.28 -0.15    3.29652
