Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-12-11 06:23:52 (GMT)
 Μέγεθος
 M 0.9
 Γεωγρ. Πλάτος
 36.4348° Β
 Γεωγρ. Μήκος
 25.4472° Α
 Εστιακό Βάθος
 8 χμ
 Αρ. αφίξεων
 20
 Επίκεντρο 2.4 χμ ΒΒΑ της Θήρας
74.9 χμ Ν της Νάξου
229.5 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
THR2HT1.7321 P06:23:53.98 0.01.0M
THR2HT1.7321 S06:23:55.34 0.21.0M
SFR2HI4.0192 P06:23:53.96 -0.11.0M
SFR2HI4.0192 S06:23:55.41 0.01.0M
THR8HT4.2138 P06:23:54.11 0.01.0M
THR8HT4.2138 S06:23:55.35 0.01.0M
THR3HT5.0235 P06:23:54.41 0.21.0M
THR3HT5.0235 S06:23:55.29 -0.21.0M
SANTHL7.2171 P06:23:54.55 0.01.0M
SANTHL7.2171 S06:23:55.90 -0.21.0M
THERAHL7.9162 P06:23:54.60 0.01.0M
THERAHL7.9162 S06:23:56.07 -0.11.0M
THR5HT9.1258 P06:23:54.91 0.21.0M
THR5HT9.1258 S06:23:56.26 -0.21.0M
THR6HT9.8207 P06:23:54.87 0.11.0M
THR6HT9.8207 S06:23:56.44 -0.11.0M
THR9HT11.8223 P06:23:55.22 0.11.0M
THR9HT11.8223 S06:23:57.10 0.01.0M
APEHL71.3 5 P06:24:04.98 0.11.0M
APEHL71.3 5 S06:24:14.08 -0.21.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024ygvf
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-12-11
    Time                  06:23:52.39
    Latitude              36.4348 deg  +/-      0 km
    Longitude             25.4472 deg  +/-      0 km
    Depth                       8 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.15 s
    Azimuthal gap             132 deg

2 Network magnitudes:
    MLv       0.93 +/- 0.34   8
    M         0.93            8 preferred

20 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    THR2  HT    0.0 321  P       06:23:53.98   0.0 M  1.0  THR2
    THR2  HT    0.0 321  S       06:23:55.34   0.2 M  1.0  THR2
    SFR2  HI    0.0 192  P       06:23:53.96  -0.1 M  1.0  SFR2
    SFR2  HI    0.0 192  S       06:23:55.41   0.0 M  1.0  SFR2
    THR8  HT    0.0 138  P       06:23:54.11   0.0 M  1.0  THR8
    THR8  HT    0.0 138  S       06:23:55.35  -0.0 M  1.0  THR8
    THR3  HT    0.0 235  P       06:23:54.41   0.2 M  1.0  THR3
    THR3  HT    0.0 235  S       06:23:55.29  -0.2 M  1.0  THR3
    SANT  HL    0.1 171  P       06:23:54.55   0.0 M  1.0  SANT
    SANT  HL    0.1 171  S       06:23:55.90  -0.2 M  1.0  SANT
    THERA HL    0.1 162  P       06:23:54.60   0.0 M  1.0  THERA
    THERA HL    0.1 162  S       06:23:56.07  -0.1 M  1.0  THERA
    THR5  HT    0.1 258  P       06:23:54.91   0.2 M  1.0  THR5
    THR5  HT    0.1 258  S       06:23:56.26  -0.2 M  1.0  THR5
    THR6  HT    0.1 207  P       06:23:54.87   0.1 M  1.0  THR6
    THR6  HT    0.1 207  S       06:23:56.44  -0.1 M  1.0  THR6
    THR9  HT    0.1 223  P       06:23:55.22   0.1 M  1.0  THR9
    THR9  HT    0.1 223  S       06:23:57.10  -0.0 M  1.0  THR9
    APE   HL    0.6   5  P       06:24:04.98   0.1 M  1.0  APE
    APE   HL    0.6   5  S       06:24:14.08  -0.2 M  1.0  APE

10 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    THR2  HT    0.0 321  MLv     0.80 -0.13    1.05057
    SFR2  HI    0.0 192  MLv     1.49  0.56    1.95587
    THR8  HT    0.0 138  MLv     0.66 -0.28   0.648526
    THR3  HT    0.0 235  MLv     0.63 -0.30   0.671032
    SANT  HL    0.1 171  MLv     0.69 -0.24   0.194354
    THERA HL    0.1 162  MLv     0.51 -0.42   0.164553
    THR5  HT    0.1 258  MLv     0.72 -0.21    1.93349
    THR6  HT    0.1 207  MLv     1.15  0.22    1.14347
    THR9  HT    0.1 223  MLv     1.37  0.44     3.4317
    APE   HL    0.6   5  MLv     1.72  0.78   0.114659
