Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-12-10 20:10:26 (GMT)
 Μέγεθος
 M 2.3
 Γεωγρ. Πλάτος
 36.5227° Β
 Γεωγρ. Μήκος
 25.5153° Α
 Εστιακό Βάθος
 9 χμ
 Αρ. αφίξεων
 25
 Επίκεντρο 13.9 χμ ΒΒΑ της Θήρας
66.0 χμ Ν της Νάξου
226.4 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
THR2HT11.0220 P20:10:29.16 0.11.0M
THR2HT11.0220 S20:10:31.17 0.11.0M
THR8HT13.3194 P20:10:29.48 0.11.0M
SFR2HI15.3207 P20:10:29.70 0.01.0M
SFR2HI15.3207 S20:10:32.07 -0.11.0M
THR3HT16.3219 P20:10:30.00 0.21.0M
THR3HT16.3219 S20:10:32.29 -0.11.0M
SANTHL17.6197 P20:10:30.14 0.11.0M
SANTHL17.6197 S20:10:32.83 -0.11.0M
THERAHL17.7192 P20:10:30.12 0.11.0M
THERAHL17.7192 S20:10:32.59 -0.31.0M
THR5HT19.0232 P20:10:30.25 0.01.0M
THR5HT19.0232 S20:10:33.02 -0.21.0M
AKROHT21.1210 P20:10:30.86 0.31.0M
AKROHT21.1210 S20:10:33.86 0.11.0M
THR6HT21.3210 P20:10:30.87 0.21.0M
THR6HT21.3210 S20:10:33.59 -0.21.0M
THR9HT23.2218 P20:10:31.05 0.11.0M
THR9HT23.2218 S20:10:34.19 -0.21.0M
APEHL61.2 1 P20:10:37.13 -0.11.0M
APEHL61.2 1 S20:10:45.06 -0.31.0M
NAX1HI65.6349 P20:10:37.96 0.11.0M
NAX1HI65.6349 S20:10:46.66 0.11.0M
MIL7HL93.0283 P20:10:42.17 -0.11.0M
MIL7HL93.0283 S20:10:54.37 0.11.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024ygaz
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-12-10
    Time                  20:10:26.39
    Latitude              36.5227 deg  +/-      0 km
    Longitude             25.5153 deg  +/-      0 km
    Depth                       9 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.15 s
    Azimuthal gap             191 deg

2 Network magnitudes:
    MLv       2.30 +/- 0.16  11
    M         2.30           11 preferred

25 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    THR2  HT    0.1 220  P       20:10:29.16   0.1 M  1.0  THR2
    THR2  HT    0.1 220  S       20:10:31.17   0.1 M  1.0  THR2
    THR8  HT    0.1 194  P       20:10:29.48   0.1 M  1.0  THR8
    SFR2  HI    0.1 207  P       20:10:29.70   0.0 M  1.0  SFR2
    SFR2  HI    0.1 207  S       20:10:32.07  -0.1 M  1.0  SFR2
    THR3  HT    0.1 219  P       20:10:30.00   0.2 M  1.0  THR3
    THR3  HT    0.1 219  S       20:10:32.29  -0.1 M  1.0  THR3
    SANT  HL    0.2 197  P       20:10:30.14   0.1 M  1.0  SANT
    SANT  HL    0.2 197  S       20:10:32.83  -0.1 M  1.0  SANT
    THERA HL    0.2 192  P       20:10:30.12   0.1 M  1.0  THERA
    THERA HL    0.2 192  S       20:10:32.59  -0.3 M  1.0  THERA
    THR5  HT    0.2 232  P       20:10:30.25  -0.0 M  1.0  THR5
    THR5  HT    0.2 232  S       20:10:33.02  -0.2 M  1.0  THR5
    AKRO  HT    0.2 210  P       20:10:30.86   0.3 M  1.0  AKRO
    AKRO  HT    0.2 210  S       20:10:33.86   0.1 M  1.0  AKRO
    THR6  HT    0.2 210  P       20:10:30.87   0.2 M  1.0  THR6
    THR6  HT    0.2 210  S       20:10:33.59  -0.2 M  1.0  THR6
    THR9  HT    0.2 218  P       20:10:31.05   0.1 M  1.0  THR9
    THR9  HT    0.2 218  S       20:10:34.19  -0.2 M  1.0  THR9
    APE   HL    0.5   1  P       20:10:37.13  -0.1 M  1.0  APE
    APE   HL    0.5   1  S       20:10:45.06  -0.3 M  1.0  APE
    NAX1  HI    0.6 349  P       20:10:37.96   0.1 M  1.0  NAX1
    NAX1  HI    0.6 349  S       20:10:46.66   0.1 M  1.0  NAX1
    MIL7  HL    0.8 283  P       20:10:42.17  -0.1 M  1.0  MIL7
    MIL7  HL    0.8 283  S       20:10:54.37   0.1 M  1.0  MIL7

13 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    THR2  HT    0.1 220  MLv     2.58  0.28    36.6846
    THR8  HT    0.1 194  MLv     1.99 -0.31    8.26573
    SFR2  HI    0.1 207  MLv     2.49  0.20    10.2604
    THR3  HT    0.1 219  MLv     2.36  0.07    18.9431
    SANT  HL    0.2 197  MLv     2.27 -0.02    4.09111
    THERA HL    0.2 192  MLv     1.80 -0.50    1.81468
    THR5  HT    0.2 232  MLv     2.29 -0.01    39.9486
    AKRO  HT    0.2 210  MLv     2.21 -0.09    3.81163
    THR6  HT    0.2 210  MLv     2.49  0.19    12.8502
    THR9  HT    0.2 218  MLv     2.06 -0.24    8.69163
    APE   HL    0.5   1  MLv     2.21 -0.08   0.405277
    NAX1  HI    0.6 349  MLv     2.29 -0.00   0.464165
    MIL7  HL    0.8 283  MLv     2.63  0.33   0.730681
