Πληροφορίες Σεισμού
 Χρόνος Γένεσης
2024-12-10 17:00:08 (GMT)
 Μέγεθος
M 2.3
 Γεωγρ. Πλάτος
38.6036° Β
 Γεωγρ. Μήκος
23.5019° Α
 Εστιακό Βάθος
10 χμ
 Αρ. αφίξεων
43
 Επίκεντρο 17.7 χμ ΒΒΔ της Χαλκίδας
35.0 χμ ΒΒΑ της Θήβας
71.9 χμ ΒΒΔ της Αθήνας
 Τύπος Λύσης
Αυτόματη
 Αρχεία / Σύνδεσμοι
QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
PSAHHA13.2107 P17:00:11.12 -0.21.0A
MRKAHA13.4 33 P17:00:10.93 -0.41.0A
GR261Y24.0199 P17:00:12.10 -0.91.0A
GR231Y32.8314 P17:00:13.53 -0.81.0A
ERTRHA33.1131 P17:00:14.05 -0.31.0A
THIVHA37.0204 P17:00:14.48 -0.51.0A
AMPEHA39.2211 P17:00:14.70 -0.71.0A
ATALHA42.9283 P17:00:15.13 -0.81.0A
LKRHL44.0277 P17:00:14.88 -1.31.0A
VILLHA51.6199 P17:00:16.28 -1.01.0A
MDRAHA60.5183 P17:00:18.29 -0.41.0A
ALIOHA61.6166 P17:00:18.59 -0.31.0A
ACHLHT65.2314 P17:00:18.72 -0.71.0A
MRTHHA65.8144 P17:00:19.39 -0.11.0A
PRDMHA67.4238 P17:00:18.35 -1.41.0A
ATHHL72.5165 P17:00:20.57 0.01.0A
NOACHL72.5165 P17:00:20.62 0.11.0A
ATHUHA75.0161 P17:00:20.78 -0.21.0A
AXARHA75.4284 P17:00:20.75 -0.31.0A
GR271Y79.1126 P17:00:21.76 0.11.0A
GR221Y79.6313 P17:00:20.88 -0.81.0A
LTKHP79.7216 P17:00:20.97 -0.71.0A
NEOHL81.7343 P17:00:21.82 -0.21.0A
LOUTHA82.5214 P17:00:21.69 -0.41.0A
DSFHP87.5256 P17:00:22.18 -0.81.0A
ACORHA96.6215 P17:00:24.55 0.21.0A
THALHA96.6229 P17:00:24.92 0.61.0A
KARYHA103.4128 P17:00:25.81 0.41.0A
EPIDHA115.0197 P17:00:27.75 0.61.0A
GR211Y120.9315 P17:00:28.70 0.71.0A
GURHP125.5234 P17:00:29.14 0.51.0A
TRIZCL127.2258 P17:00:29.95 1.11.0A
PYRGCL131.0261 P17:00:30.53 1.11.0A
KLVHL133.3243 P17:00:29.96 0.31.0A
ANXHP137.4270 P17:00:30.86 0.61.0A
LAKAHA138.7254 P17:00:31.83 1.41.0A
KRNDHT139.2193 P17:00:31.32 0.91.0A
ROD3CL144.0257 P17:00:33.05 1.91.0A
PAIGHT149.0 6 P17:00:31.65 -0.11.0A
GR321Y187.5194 P17:00:37.31 0.51.0A
OURHT196.8 12 P17:00:37.89 -0.11.0A
HORTHT224.4351 P17:00:42.82 1.31.0A
KTHAHL263.8189 P17:00:47.23 0.81.0A


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024yfus
    Description
      region name: Greece
Origin:
    Date                   2024-12-10
    Time                  17:00:07.51  +/-    0.2 s
    Latitude              38.6036 deg  +/-      2 km
    Longitude             23.5019 deg  +/-      2 km
    Depth                      10 km
    Agency                 HA
    Mode                   automatic
    Status                 NOT SET
    Residual RMS             0.75 s
    Azimuthal gap              74 deg

2 Network magnitudes:
    MLv       2.32 +/- 0.17  33
    M         2.32           33 preferred

43 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    PSAH  HA    0.1 107  P       17:00:11.12  -0.2 A  1.0  PSAH
    MRKA  HA    0.1  33  P       17:00:10.93  -0.4 A  1.0  MRKA
    GR26  1Y    0.2 199  P       17:00:12.10  -0.9 A  1.0  GR26
    GR23  1Y    0.3 314  P       17:00:13.53  -0.8 A  1.0  GR23
    ERTR  HA    0.3 131  P       17:00:14.05  -0.3 A  1.0  ERTR
    THIV  HA    0.3 204  P       17:00:14.48  -0.5 A  1.0  THIV
    AMPE  HA    0.4 211  P       17:00:14.70  -0.7 A  1.0  AMPE
    ATAL  HA    0.4 283  P       17:00:15.13  -0.8 A  1.0  ATAL
    LKR   HL    0.4 277  P       17:00:14.88  -1.3 A  1.0  LKR
    VILL  HA    0.5 199  P       17:00:16.28  -1.0 A  1.0  VILL
    MDRA  HA    0.5 183  P       17:00:18.29  -0.4 A  1.0  MDRA
    ALIO  HA    0.6 166  P       17:00:18.59  -0.3 A  1.0  ALIO
    ACHL  HT    0.6 314  P       17:00:18.72  -0.7 A  1.0  ACHL
    MRTH  HA    0.6 144  P       17:00:19.39  -0.1 A  1.0  MRTH
    PRDM  HA    0.6 238  P       17:00:18.35  -1.4 A  1.0  PRDM
    ATH   HL    0.7 165  P       17:00:20.57   0.0 A  1.0  ATH
    NOAC  HL    0.7 165  P       17:00:20.62   0.1 A  1.0  NOAC
    ATHU  HA    0.7 161  P       17:00:20.78  -0.2 A  1.0  ATHU
    AXAR  HA    0.7 284  P       17:00:20.75  -0.3 A  1.0  AXAR
    GR27  1Y    0.7 126  P       17:00:21.76   0.1 A  1.0  GR27
    GR22  1Y    0.7 313  P       17:00:20.88  -0.8 A  1.0  GR22
    LTK   HP    0.7 216  P       17:00:20.97  -0.7 A  1.0  LTK
    NEO   HL    0.7 343  P       17:00:21.82  -0.2 A  1.0  NEO
    LOUT  HA    0.7 214  P       17:00:21.69  -0.4 A  1.0  LOUT
    DSF   HP    0.8 256  P       17:00:22.18  -0.8 A  1.0  DSF
    THAL  HA    0.9 229  P       17:00:24.92   0.6 A  1.0  THAL
    ACOR  HA    0.9 215  P       17:00:24.55   0.2 A  1.0  ACOR
    KARY  HA    0.9 128  P       17:00:25.81   0.4 A  1.0  KARY
    EPID  HA    1.0 197  P       17:00:27.75   0.6 A  1.0  EPID
    GR21  1Y    1.1 315  P       17:00:28.70   0.7 A  1.0  GR21
    GUR   HP    1.1 234  P       17:00:29.14   0.5 A  1.0  GUR
    TRIZ  CL    1.1 258  P       17:00:29.95   1.1 A  1.0  TRIZ
    PYRG  CL    1.2 261  P       17:00:30.53   1.1 A  1.0  PYRG
    KLV   HL    1.2 243  P       17:00:29.96   0.3 A  1.0  KLV
    ANX   HP    1.2 270  P       17:00:30.86   0.6 A  1.0  ANX
    LAKA  HA    1.2 254  P       17:00:31.83   1.4 A  1.0  LAKA
    KRND  HT    1.3 193  P       17:00:31.32   0.9 A  1.0  KRND
    ROD3  CL    1.3 257  P       17:00:33.05   1.9 A  1.0  ROD3
    PAIG  HT    1.3   6  P       17:00:31.65  -0.1 A  1.0  PAIG
    GR32  1Y    1.7 194  P       17:00:37.31   0.5 A  1.0  GR32
    OUR   HT    1.8  12  P       17:00:37.89  -0.1 A  1.0  OUR
    HORT  HT    2.0 351  P       17:00:42.82   1.3 A  1.0  HORT
    KTHA  HL    2.4 189  P       17:00:47.23   0.8 A  1.0  KTHA

43 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    PSAH  HA    0.1 107  MLv     2.25 -0.07    6.64114
    MRKA  HA    0.1  33  MLv     2.13 -0.19    5.01854
    GR26  1Y    0.2 199  MLv     1.94 -0.39     1.7238
    GR23  1Y    0.3 314  MLv     2.21 -0.12    1.94042
    ERTR  HA    0.3 131  MLv     2.16 -0.16    1.72166
    THIV  HA    0.3 204  MLv     2.57  0.24    3.48117
    AMPE  HA    0.4 211  MLv     2.13 -0.19     1.1227
    ATAL  HA    0.4 283  MLv     2.09 -0.24   0.822095
    LKR   HL    0.4 277  MLv     2.29 -0.03   0.662187
    VILL  HA    0.5 199  MLv     2.26 -0.07   0.735912
    MDRA  HA    0.5 183  MLv     2.45  0.12   0.700628
    ALIO  HA    0.6 166  MLv     2.62  0.29    1.02529
    ACHL  HT    0.6 314  MLv     2.23 -0.10   0.400661
    MRTH  HA    0.6 144  MLv     2.78  0.45    1.40686
    PRDM  HA    0.6 238  MLv     2.34  0.02   0.506479
    ATH   HL    0.7 165  MLv     2.68  0.35    1.03134
    NOAC  HL    0.7 165  MLv     2.76  0.44    1.25148
    ATHU  HA    0.7 161  MLv     2.48  0.16   0.395663
    AXAR  HA    0.7 284  MLv     1.80 -0.52   0.534357
    GR27  1Y    0.7 126  MLv     2.45  0.13    0.57359
    GR22  1Y    0.7 313  MLv     2.42  0.10   0.529906
    LTK   HP    0.7 216  MLv     1.89 -0.43   0.596233
    NEO   HL    0.7 343  MLv     2.83  0.51    1.82624
    LOUT  HA    0.7 214  MLv     2.52  0.20   0.640786
    DSF   HP    0.8 256  MLv     2.51  0.19   0.599553
    THAL  HA    0.9 229  MLv     2.26 -0.07   0.527624
    ACOR  HA    0.9 215  MLv     2.19 -0.13   0.257029
    KARY  HA    0.9 128  MLv     2.58  0.26   0.582553
    EPID  HA    1.0 197  MLv     2.59  0.26   0.517133
    GR21  1Y    1.1 315  MLv     1.93 -0.39   0.106387
    GUR   HP    1.1 234  MLv     2.39  0.07   0.292447
    TRIZ  CL    1.1 258  MLv     2.09 -0.23   0.143999
    PYRG  CL    1.2 261  MLv     1.53 -0.79   0.0237318
    KLV   HL    1.2 243  MLv     2.36  0.04   0.189661
    ANX   HP    1.2 270  MLv     2.15 -0.17   0.145717
    LAKA  HA    1.2 254  MLv     1.95 -0.37   0.0907836
    KRND  HT    1.3 193  MLv     2.52  0.20   0.335643
    ROD3  CL    1.3 257  MLv     2.13 -0.20   0.194529
    PAIG  HT    1.3   6  MLv     2.13 -0.20   0.093329
    GR32  1Y    1.7 194  MLv     2.54  0.22   0.202026
    OUR   HT    1.8  12  MLv     2.34  0.02   0.114947
    HORT  HT    2.0 351  MLv     2.31 -0.01   0.0528369
    KTHA  HL    2.4 189  MLv     3.20  0.88   0.382751
