Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-11-20 17:22:21 (GMT)
 Μέγεθος
 M 2.1
 Γεωγρ. Πλάτος
 36.5528° Β
 Γεωγρ. Μήκος
 25.5353° Α
 Εστιακό Βάθος
 7 χμ
 Αρ. αφίξεων
 23
 Επίκεντρο 17.7 χμ ΒΒΑ της Θήρας
63.1 χμ ΝΝΑ της Νάξου
225.2 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
CMBOHT14.7232 P17:22:23.81 -0.11.0M
CMBOHT14.7232 S17:22:26.35 0.11.0M
THR2HT14.8217 P17:22:24.01 0.11.0M
THR8HT17.0197 P17:22:24.30 0.11.0M
THR8HT17.0197 S17:22:26.45 -0.41.0M
SFR2HI19.1207 P17:22:24.66 0.11.0M
SFR2HI19.1207 S17:22:27.55 0.01.0M
THR3HT20.0217 P17:22:24.83 0.11.0M
THR3HT20.0217 S17:22:27.64 -0.11.0M
THERAHL21.3195 P17:22:24.90 -0.11.0M
THERAHL21.3195 S17:22:27.87 -0.31.0M
THR5HT22.5228 P17:22:25.11 -0.11.0M
THR5HT22.5228 S17:22:28.52 0.01.0M
AKROHT24.9210 P17:22:25.44 -0.11.0M
AKROHT24.9210 S17:22:28.95 -0.31.0M
THR6HT25.1210 P17:22:25.66 0.11.0M
THR6HT25.1210 S17:22:29.20 -0.11.0M
THR9HT26.9216 P17:22:26.30 0.41.0M
THR9HT26.9216 S17:22:29.81 0.01.0M
APEHL57.8359 P17:22:31.22 0.21.0M
APEHL57.8359 S17:22:38.48 -0.31.0M
MIL7HL94.0281 P17:22:37.15 0.31.0M
MIL7HL94.0281 S17:22:49.00 -0.11.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024wvhj
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-11-20
    Time                  17:22:20.73
    Latitude              36.5528 deg  +/-      0 km
    Longitude             25.5353 deg  +/-      0 km
    Depth                       7 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.21 s
    Azimuthal gap             196 deg

2 Network magnitudes:
    MLv       2.06 +/- 0.10  10
    M         2.06           10 preferred

23 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    CMBO  HT    0.1 232  P       17:22:23.81  -0.1 M  1.0  CMBO
    CMBO  HT    0.1 232  S       17:22:26.35   0.1 M  1.0  CMBO
    THR2  HT    0.1 217  P       17:22:24.01   0.1 M  1.0  THR2
    THR8  HT    0.2 197  P       17:22:24.30   0.1 M  1.0  THR8
    THR8  HT    0.2 197  S       17:22:26.45  -0.4 M  1.0  THR8
    SFR2  HI    0.2 207  P       17:22:24.66   0.1 M  1.0  SFR2
    SFR2  HI    0.2 207  S       17:22:27.55   0.0 M  1.0  SFR2
    THR3  HT    0.2 217  P       17:22:24.83   0.1 M  1.0  THR3
    THR3  HT    0.2 217  S       17:22:27.64  -0.1 M  1.0  THR3
    THERA HL    0.2 195  P       17:22:24.90  -0.1 M  1.0  THERA
    THERA HL    0.2 195  S       17:22:27.87  -0.3 M  1.0  THERA
    THR5  HT    0.2 228  P       17:22:25.11  -0.1 M  1.0  THR5
    THR5  HT    0.2 228  S       17:22:28.52  -0.0 M  1.0  THR5
    AKRO  HT    0.2 210  P       17:22:25.44  -0.1 M  1.0  AKRO
    AKRO  HT    0.2 210  S       17:22:28.95  -0.3 M  1.0  AKRO
    THR6  HT    0.2 210  P       17:22:25.66   0.1 M  1.0  THR6
    THR6  HT    0.2 210  S       17:22:29.20  -0.1 M  1.0  THR6
    THR9  HT    0.2 216  P       17:22:26.30   0.4 M  1.0  THR9
    THR9  HT    0.2 216  S       17:22:29.81   0.0 M  1.0  THR9
    APE   HL    0.5 359  P       17:22:31.22   0.2 M  1.0  APE
    APE   HL    0.5 359  S       17:22:38.48  -0.3 M  1.0  APE
    MIL7  HL    0.8 281  P       17:22:37.15   0.3 M  1.0  MIL7
    MIL7  HL    0.8 281  S       17:22:49.00  -0.1 M  1.0  MIL7

12 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    CMBO  HT    0.1 232  MLv     2.10  0.03    4.24381
    THR2  HT    0.1 217  MLv     2.28  0.22    14.9454
    THR8  HT    0.2 197  MLv     1.99 -0.08    6.62825
    SFR2  HI    0.2 207  MLv     2.18  0.11     3.9678
    THR3  HT    0.2 217  MLv     2.06 -0.00    7.59756
    THERA HL    0.2 195  MLv     1.48 -0.58   0.701698
    THR5  HT    0.2 228  MLv     1.95 -0.11    15.0198
    AKRO  HT    0.2 210  MLv     1.91 -0.15    1.54534
    THR6  HT    0.2 210  MLv     2.15  0.09    4.70102
    THR9  HT    0.2 216  MLv     1.96 -0.11    5.53432
    APE   HL    0.5 359  MLv     2.08  0.02   0.346463
    MIL7  HL    0.8 281  MLv     2.32  0.26   0.352385
