Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-11-13 12:23:20 (GMT)
 Μέγεθος
 M 1.7
 Γεωγρ. Πλάτος
 36.5253° Β
 Γεωγρ. Μήκος
 25.5073° Α
 Εστιακό Βάθος
 7 χμ
 Αρ. αφίξεων
 22
 Επίκεντρο 13.8 χμ ΒΒΑ της Θήρας
65.6 χμ Ν της Νάξου
225.7 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
THR2HT10.8217 P12:23:22.78 0.11.0M
THR2HT10.8217 S12:23:24.47 -0.11.0M
CMBOHT10.9237 P12:23:22.85 0.21.0M
CMBOHT10.9237 S12:23:24.26 -0.31.0M
THR8HT13.4191 P12:23:23.06 0.01.0M
THR8HT13.4191 S12:23:25.40 0.21.0M
THR3HT16.1217 P12:23:23.53 0.11.0M
THR3HT16.1217 S12:23:25.88 -0.11.0M
SANTHL17.7194 P12:23:23.71 -0.11.0M
SANTHL17.7194 S12:23:26.36 -0.31.0M
THERAHL17.8189 P12:23:23.72 -0.11.0M
THERAHL17.8189 S12:23:26.34 -0.21.0M
THR5HT18.6230 P12:23:23.84 -0.11.0M
THR5HT18.6230 S12:23:27.13 0.31.0M
AKROHT21.0208 P12:23:24.34 0.01.0M
AKROHT21.0208 S12:23:27.80 0.31.0M
THR6HT21.2208 P12:23:24.51 0.21.0M
THR6HT21.2208 S12:23:27.48 0.01.0M
THR9HT23.0216 P12:23:25.01 0.41.0M
THR9HT23.0216 S12:23:27.89 -0.11.0M
APEHL60.9 1 P12:23:30.93 0.11.0M
APEHL60.9 1 S12:23:38.98 -0.11.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024wicz
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-11-13
    Time                  12:23:20.14
    Latitude              36.5253 deg  +/-      0 km
    Longitude             25.5073 deg  +/-      0 km
    Depth                       7 km   +/-    0 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.13 s
    Azimuthal gap             188 deg

2 Network magnitudes:
    MLv       1.70 +/- 0.21   9
    M         1.70            9 preferred

22 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    THR2  HT    0.1 217  P       12:23:22.78   0.1 M  1.0  THR2
    THR2  HT    0.1 217  S       12:23:24.47  -0.1 M  1.0  THR2
    CMBO  HT    0.1 237  P       12:23:22.85   0.2 M  1.0  CMBO
    CMBO  HT    0.1 237  S       12:23:24.26  -0.3 M  1.0  CMBO
    THR8  HT    0.1 191  P       12:23:23.06   0.0 M  1.0  THR8
    THR8  HT    0.1 191  S       12:23:25.40   0.2 M  1.0  THR8
    THR3  HT    0.1 217  P       12:23:23.53   0.1 M  1.0  THR3
    THR3  HT    0.1 217  S       12:23:25.88  -0.1 M  1.0  THR3
    SANT  HL    0.2 194  P       12:23:23.71  -0.1 M  1.0  SANT
    SANT  HL    0.2 194  S       12:23:26.36  -0.3 M  1.0  SANT
    THERA HL    0.2 189  P       12:23:23.72  -0.1 M  1.0  THERA
    THERA HL    0.2 189  S       12:23:26.34  -0.2 M  1.0  THERA
    THR5  HT    0.2 230  P       12:23:23.84  -0.1 M  1.0  THR5
    THR5  HT    0.2 230  S       12:23:27.13   0.3 M  1.0  THR5
    AKRO  HT    0.2 208  P       12:23:24.34   0.0 M  1.0  AKRO
    AKRO  HT    0.2 208  S       12:23:27.80   0.3 M  1.0  AKRO
    THR6  HT    0.2 208  P       12:23:24.51   0.2 M  1.0  THR6
    THR6  HT    0.2 208  S       12:23:27.48  -0.0 M  1.0  THR6
    THR9  HT    0.2 216  P       12:23:25.01   0.4 M  1.0  THR9
    THR9  HT    0.2 216  S       12:23:27.89  -0.1 M  1.0  THR9
    APE   HL    0.5   1  P       12:23:30.93   0.1 M  1.0  APE
    APE   HL    0.5   1  S       12:23:38.98  -0.1 M  1.0  APE

11 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    THR2  HT    0.1 217  MLv     2.01  0.31    10.0377
    CMBO  HT    0.1 237  MLv     1.79  0.08    2.58528
    THR8  HT    0.1 191  MLv     1.88  0.18    6.41237
    THR3  HT    0.1 217  MLv     1.59 -0.12      3.216
    SANT  HL    0.2 194  MLv     1.83  0.13    1.48156
    THERA HL    0.2 189  MLv     1.30 -0.41   0.561979
    THR5  HT    0.2 230  MLv     1.32 -0.38    4.44088
    AKRO  HT    0.2 208  MLv     1.68 -0.02    1.13274
    THR6  HT    0.2 208  MLv     1.92  0.22    3.46459
    THR9  HT    0.2 216  MLv     1.39 -0.31    1.90289
    APE   HL    0.5   1  MLv     1.86  0.16   0.181787
