Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-10-13 01:29:15 (GMT)
Πανεπιστήμιο Αθηνών - Εργαστήριο Σεισμολογίας
+−
10 km
5 mi
Leaflet | Tiles © Esri
 Μέγεθος
 M 1.8
 Γεωγρ. Πλάτος
 36.5085° Β
 Γεωγρ. Μήκος
 25.4435° Α
 Εστιακό Βάθος
 11 χμ
 Αρ. αφίξεων
 20
 Επίκεντρο 10.2 χμ Β της Θήρας
66.7 χμ Ν της Νάξου
223.2 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
CMBOHT5.4219 P01:29:17.47 0.01.0M
CMBOHT5.4219 S01:29:18.75 -0.41.0M
THR2HT6.9186 P01:29:17.71 0.11.0M
THR2HT6.9186 S01:29:19.43 0.01.0M
SNT1HA10.4188 P01:29:17.98 0.01.0M
SNT1HA10.4188 S01:29:19.91 -0.11.0M
THR3HT11.7199 P01:29:18.50 0.31.0M
THR3HT11.7199 S01:29:20.27 -0.11.0M
THR8HT11.7164 P01:29:18.09 -0.11.0M
THR8HT11.7164 S01:29:20.43 0.11.0M
SFR2HI12.1182 P01:29:18.44 0.21.0M
SFR2HI12.1182 S01:29:20.70 0.21.0M
THR5HT13.3220 P01:29:18.74 0.41.0M
THR5HT13.3220 S01:29:20.60 -0.21.0M
THERAHL16.0170 P01:29:18.69 -0.11.0M
THERAHL16.0170 S01:29:21.37 -0.11.0M
THR6HT17.4194 P01:29:19.42 0.51.0M
THR6HT17.4194 S01:29:22.12 0.31.0M
APEHL63.1 6 P01:29:25.88 -0.41.0M
APEHL63.1 6 S01:29:35.02 0.31.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024ucqv
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-10-13
    Time                  01:29:15.25
    Latitude              36.5085 deg  +/-      1 km
    Longitude             25.4435 deg  +/-      1 km
    Depth                      11 km   +/-    2 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.26 s
    Azimuthal gap             158 deg

2 Network magnitudes:
    MLv       1.80 +/- 0.12   8
    M         1.80            8 preferred

20 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    CMBO  HT    0.0 219  P       01:29:17.47   0.0 M  1.0  CMBO
    CMBO  HT    0.0 219  S       01:29:18.75  -0.4 M  1.0  CMBO
    THR2  HT    0.1 186  P       01:29:17.71   0.1 M  1.0  THR2
    THR2  HT    0.1 186  S       01:29:19.43   0.0 M  1.0  THR2
    SNT1  HA    0.1 188  P       01:29:17.98   0.0 M  1.0  SNT1
    SNT1  HA    0.1 188  S       01:29:19.91  -0.1 M  1.0  SNT1
    THR3  HT    0.1 199  P       01:29:18.50   0.3 M  1.0  THR3
    THR3  HT    0.1 199  S       01:29:20.27  -0.1 M  1.0  THR3
    THR8  HT    0.1 164  P       01:29:18.09  -0.1 M  1.0  THR8
    THR8  HT    0.1 164  S       01:29:20.43   0.1 M  1.0  THR8
    SFR2  HI    0.1 182  P       01:29:18.44   0.2 M  1.0  SFR2
    SFR2  HI    0.1 182  S       01:29:20.70   0.2 M  1.0  SFR2
    THR5  HT    0.1 220  P       01:29:18.74   0.4 M  1.0  THR5
    THR5  HT    0.1 220  S       01:29:20.60  -0.2 M  1.0  THR5
    THERA HL    0.1 170  P       01:29:18.69  -0.1 M  1.0  THERA
    THERA HL    0.1 170  S       01:29:21.37  -0.1 M  1.0  THERA
    THR6  HT    0.2 194  P       01:29:19.42   0.5 M  1.0  THR6
    THR6  HT    0.2 194  S       01:29:22.12   0.3 M  1.0  THR6
    APE   HL    0.6   6  P       01:29:25.88  -0.4 M  1.0  APE
    APE   HL    0.6   6  S       01:29:35.02   0.3 M  1.0  APE

10 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    CMBO  HT    0.0 219  MLv     1.90  0.09     4.6079
    THR2  HT    0.1 186  MLv     2.02  0.21    12.7155
    SNT1  HA    0.1 188  MLv     1.63 -0.18    1.22309
    THR3  HT    0.1 199  MLv     1.71 -0.09    5.46629
    THR8  HT    0.1 164  MLv     1.71 -0.09    4.75784
    SFR2  HI    0.1 182  MLv     1.88  0.08     3.0236
    THR5  HT    0.1 220  MLv     1.78 -0.02    17.4002
    THERA HL    0.1 170  MLv     1.21 -0.60   0.509745
    THR6  HT    0.2 194  MLv     1.82  0.01    3.38994
    APE   HL    0.6   6  MLv     2.08  0.28   0.291513
