Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-10-01 20:32:18 (GMT)
Πανεπιστήμιο Αθηνών - Εργαστήριο Σεισμολογίας
+−
10 km
5 mi
Leaflet | Tiles © Esri
 Μέγεθος
 M 1.0
 Γεωγρ. Πλάτος
 36.4175° Β
 Γεωγρ. Μήκος
 25.4288° Α
 Εστιακό Βάθος
 5 χμ
 Αρ. αφίξεων
 21
 Επίκεντρο 0.4 χμ ΔΒΔ της Θήρας
76.7 χμ Ν της Νάξου
229.9 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
SNT1HA0.2198 P20:32:19.06 -0.11.0M
SNT1HA0.2198 S20:32:19.88 -0.11.0M
THR3HT2.7250 P20:32:19.29 0.01.0M
THR3HT2.7250 S20:32:20.38 0.11.0M
THR2HT3.3 10 P20:32:19.38 0.01.0M
THR2HT3.3 10 S20:32:20.39 0.01.0M
THR8HT4.6105 P20:32:19.60 0.11.0M
THR8HT4.6105 S20:32:20.66 0.11.0M
SANTHL5.9152 P20:32:19.77 0.01.0M
SANTHL5.9152 S20:32:21.05 0.01.0M
CMBOHT6.3341 P20:32:19.72 0.01.0M
CMBOHT6.3341 S20:32:21.01 0.01.0M
THERAHL7.0144 P20:32:19.94 0.11.0M
THERAHL7.0144 S20:32:21.23 0.01.0M
AKROHT7.2204 P20:32:19.78 -0.11.0M
THR5HT7.2270 P20:32:19.87 0.01.0M
THR5HT7.2270 S20:32:21.35 0.11.0M
THR6HT7.4202 P20:32:19.82 -0.11.0M
THR6HT7.4202 S20:32:21.26 -0.11.0M
THR9HT9.3224 P20:32:20.31 0.11.0M
THR9HT9.3224 S20:32:22.24 0.41.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024tiel
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-10-01
    Time                  20:32:18.08
    Latitude              36.4175 deg  +/-      0 km
    Longitude             25.4288 deg  +/-      0 km
    Depth                       5 km   +/-    0 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.07 s
    Azimuthal gap              95 deg

2 Network magnitudes:
    MLv       1.00 +/- 0.20   9
    M         1.00            9 preferred

21 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    SNT1  HA    0.0 198  P       20:32:19.06  -0.1 M  1.0  SNT1
    SNT1  HA    0.0 198  S       20:32:19.88  -0.1 M  1.0  SNT1
    THR3  HT    0.0 250  P       20:32:19.29  -0.0 M  1.0  THR3
    THR3  HT    0.0 250  S       20:32:20.38   0.1 M  1.0  THR3
    THR2  HT    0.0  10  P       20:32:19.38   0.0 M  1.0  THR2
    THR2  HT    0.0  10  S       20:32:20.39   0.0 M  1.0  THR2
    THR8  HT    0.0 105  P       20:32:19.60   0.1 M  1.0  THR8
    THR8  HT    0.0 105  S       20:32:20.66   0.1 M  1.0  THR8
    SANT  HL    0.1 152  P       20:32:19.77   0.0 M  1.0  SANT
    SANT  HL    0.1 152  S       20:32:21.05   0.0 M  1.0  SANT
    CMBO  HT    0.1 341  P       20:32:19.72  -0.0 M  1.0  CMBO
    CMBO  HT    0.1 341  S       20:32:21.01   0.0 M  1.0  CMBO
    THERA HL    0.1 144  P       20:32:19.94   0.1 M  1.0  THERA
    THERA HL    0.1 144  S       20:32:21.23  -0.0 M  1.0  THERA
    AKRO  HT    0.1 204  P       20:32:19.78  -0.1 M  1.0  AKRO
    THR5  HT    0.1 270  P       20:32:19.87  -0.0 M  1.0  THR5
    THR5  HT    0.1 270  S       20:32:21.35   0.1 M  1.0  THR5
    THR6  HT    0.1 202  P       20:32:19.82  -0.1 M  1.0  THR6
    THR6  HT    0.1 202  S       20:32:21.26  -0.1 M  1.0  THR6
    THR9  HT    0.1 224  P       20:32:20.31   0.1 M  1.0  THR9
    THR9  HT    0.1 224  S       20:32:22.24   0.4 M  1.0  THR9

11 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    SNT1  HA    0.0 198  MLv     1.15  0.16   0.739454
    THR3  HT    0.0 250  MLv     1.24  0.25    3.14736
    THR2  HT    0.0  10  MLv     1.33  0.34     3.2456
    THR8  HT    0.0 105  MLv     0.84 -0.16   0.963331
    SANT  HL    0.1 152  MLv     2.86  1.86    30.9443
    CMBO  HT    0.1 341  MLv     1.03  0.03    0.58963
    THERA HL    0.1 144  MLv     0.55 -0.45    0.18686
    AKRO  HT    0.1 204  MLv     0.95 -0.04   0.471925
    THR5  HT    0.1 270  MLv     0.91 -0.09    3.30079
    THR6  HT    0.1 202  MLv     0.83 -0.17    0.62648
    THR9  HT    0.1 224  MLv     0.68 -0.32   0.811589
