Πληροφορίες Σεισμού
 Χρόνος Γένεσης
 2024-09-21 07:02:20 (GMT)
Πανεπιστήμιο Αθηνών - Εργαστήριο Σεισμολογίας
+−
10 km
5 mi
Leaflet | Tiles © Esri
 Μέγεθος
 M 1.5
 Γεωγρ. Πλάτος
 36.4160° Β
 Γεωγρ. Μήκος
 25.4222° Α
 Εστιακό Βάθος
 5 χμ
 Αρ. αφίξεων
 22
 Επίκεντρο 1.0 χμ Δ της Θήρας
76.8 χμ Ν της Νάξου
229.7 χμ ΝΑ της Αθήνας
 Τύπος Λύσης
 Χειρακτική (από αναλυτή)
 Αρχεία / Σύνδεσμοι
 QuakeML  GSE2.0  Alert  .phi


  Δεδομένα σταθμών

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
SNT1HA0.5 92 P07:02:20.53 0.01.0M
SNT1HA0.5 92 S07:02:21.35 0.01.0M
THR3HT2.1248 P07:02:20.61 -0.11.0M
THR3HT2.1248 S07:02:21.59 0.11.0M
SFR2HI2.3141 P07:02:20.52 -0.21.0M
SFR2HI2.3141 S07:02:21.71 0.11.0M
THR2HT3.6 19 P07:02:20.95 0.11.0M
THR2HT3.6 19 S07:02:21.89 0.11.0M
THR8HT5.2101 P07:02:21.08 0.11.0M
THR8HT5.2101 S07:02:22.05 -0.11.0M
SANTHL6.1147 P07:02:21.24 0.01.0M
SANTHL6.1147 S07:02:22.39 -0.11.0M
CMBOHT6.3346 P07:02:21.08 -0.11.0M
CMBOHT6.3346 S07:02:22.35 -0.11.0M
THR5HT6.6271 P07:02:21.28 0.01.0M
THR5HT6.6271 S07:02:22.43 -0.11.0M
AKROHT6.8200 P07:02:21.38 0.11.0M
AKROHT6.8200 S07:02:22.51 -0.11.0M
THERAHL7.2139 P07:02:21.38 0.01.0M
THERAHL7.2139 S07:02:22.63 -0.11.0M
THR9HT8.7222 P07:02:21.71 0.11.0M
THR9HT8.7222 S07:02:23.06 0.01.0M


  Λεπτομέρειες λύσης

Event:
    Public ID              nkua2024sowt
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2024-09-21
    Time                  07:02:19.55
    Latitude              36.4160 deg  +/-      0 km
    Longitude             25.4222 deg  +/-      0 km
    Depth                       5 km   +/-    0 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.08 s
    Azimuthal gap              75 deg

2 Network magnitudes:
    MLv       1.52 +/- 0.25   8
    M         1.52            8 preferred

22 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    SNT1  HA    0.0  92  P       07:02:20.53  -0.0 M  1.0  SNT1
    SNT1  HA    0.0  92  S       07:02:21.35   0.0 M  1.0  SNT1
    THR3  HT    0.0 248  P       07:02:20.61  -0.1 M  1.0  THR3
    THR3  HT    0.0 248  S       07:02:21.59   0.1 M  1.0  THR3
    SFR2  HI    0.0 141  P       07:02:20.52  -0.2 M  1.0  SFR2
    SFR2  HI    0.0 141  S       07:02:21.71   0.1 M  1.0  SFR2
    THR2  HT    0.0  19  P       07:02:20.95   0.1 M  1.0  THR2
    THR2  HT    0.0  19  S       07:02:21.89   0.1 M  1.0  THR2
    THR8  HT    0.0 101  P       07:02:21.08   0.1 M  1.0  THR8
    THR8  HT    0.0 101  S       07:02:22.05  -0.1 M  1.0  THR8
    SANT  HL    0.1 147  P       07:02:21.24   0.0 M  1.0  SANT
    SANT  HL    0.1 147  S       07:02:22.39  -0.1 M  1.0  SANT
    CMBO  HT    0.1 346  P       07:02:21.08  -0.1 M  1.0  CMBO
    CMBO  HT    0.1 346  S       07:02:22.35  -0.1 M  1.0  CMBO
    THR5  HT    0.1 271  P       07:02:21.28   0.0 M  1.0  THR5
    THR5  HT    0.1 271  S       07:02:22.43  -0.1 M  1.0  THR5
    AKRO  HT    0.1 200  P       07:02:21.38   0.1 M  1.0  AKRO
    AKRO  HT    0.1 200  S       07:02:22.51  -0.1 M  1.0  AKRO
    THERA HL    0.1 139  P       07:02:21.38   0.0 M  1.0  THERA
    THERA HL    0.1 139  S       07:02:22.63  -0.1 M  1.0  THERA
    THR9  HT    0.1 222  P       07:02:21.71   0.1 M  1.0  THR9
    THR9  HT    0.1 222  S       07:02:23.06  -0.0 M  1.0  THR9

10 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    SNT1  HA    0.0  92  MLv     1.45 -0.07    1.42312
    THR3  HT    0.0 248  MLv     2.09  0.56     22.574
    THR2  HT    0.0  19  MLv     1.77  0.25    8.65502
    THR8  HT    0.0 101  MLv     1.42 -0.10    3.54616
    SANT  HL    0.1 147  MLv     5.28  3.76    8192.29
    CMBO  HT    0.1 346  MLv     1.34 -0.18    1.21721
    THR5  HT    0.1 271  MLv     1.25 -0.27    7.46238
    AKRO  HT    0.1 200  MLv     1.45 -0.07     1.5241
    THERA HL    0.1 139  MLv     1.10 -0.42    0.66497
    THR9  HT    0.1 222  MLv     1.48 -0.04    5.23381
